How to run inference using ONNX file

p1221371923 · March 3, 2025, 6:28pm

Hi,

I want to run inference using my custom trained yolov8. What i should do?

I have .pt file and onnx file.

Can I run inference by using onnxruntime:

or I must first convert onnx to hef file and then run inference by using i.e this code examples??

I try convert onnx to hef but i have some problems…
like:
raise FileNotFoundError(f"Couldn’t find dataset in {data_path}. Please refer to docs/DATA.rst.")
FileNotFoundError: Couldn’t find dataset in /home/usser/.hailomz/data/models_files/coco/2021-06-18/coco_calib2017.tfrecord. Please refer to docs/DATA.rst.

KlausK · March 3, 2025, 6:40pm

Welcome to the Hailo Community!

Yes, you first must convert the model into the HEF format.

The dataset mentioned here can be created using the instruction here:

GitHub - Hailo Model Zoo - DATA

However, you said

That means you need to use images from your own dataset. The Model Zoo will use the COCO dataset for this model. See

GitHub - Hailo Model Zoo - yolov8m.yaml

Check this page last section:

GitHub - Hailo Model Zoo - Training - Yolov8

If you have not done so yet, please also work trough the tutorials in the Hailo AI Software Suite about the model conversion workflow. Inside the docker simply type:

hailo tutorials

p1221371923 · March 6, 2025, 3:26pm

Thanks for your reply.

I read these documents, but I’m still confused.

To be clarify, my model is yolov8n, but I used 3 classes, and other input version (1024x1024), and this model was trained on my custom dataset.

So how can I convert it from onnx to hef ? I also need to do it with int16

After reading these docs, I get more questions:

start_node_names (list of str, optional): Name of the first ONNX node to parse.
end_node_names (list of str, optional): List of ONNX nodes, that the parsing can stop after all of them are parsed.

I understand that I can get these nodes names from my onnx file, but hm… in yolov8n I have:
Input [image, batch x channels x width x height] →

Node name: /model.0/conv/Conv
Input(s): images, model.0.conv.weight, model.0.conv.bias
Output(s): /model.0/conv/Conv_output_0
Op type: Conv

…
…
…

some convs, concat, split … etc

at the end:

…

Node name: /model.22/Div_1
Input(s): /model.22/Add_2_output_0, /model.22/Constant_11_output_0
Output(s): /model.22/Div_1_output_0
Op type: Div

Node name: /model.22/Sub_1
Input(s): /model.22/Add_1_output_0, /model.22/Sub_output_0
Output(s): /model.22/Sub_1_output_0
Op type: Sub

Node name: /model.22/Concat_4
Input(s): /model.22/Div_1_output_0, /model.22/Sub_1_output_0
Output(s): /model.22/Concat_4_output_0
Op type: Concat

Node name: /model.22/Constant_12
Input(s):
Output(s): /model.22/Constant_12_output_0
Op type: Constant

Node name: /model.22/Mul_2
Input(s): /model.22/Concat_4_output_0, /model.22/Constant_12_output_0
Output(s): /model.22/Mul_2_output_0
Op type: Mul

Node name: /model.22/Sigmoid
Input(s): /model.22/Split_output_1
Output(s): /model.22/Sigmoid_output_0
Op type: Sigmoid

Node name: /model.22/Concat_5
Input(s): /model.22/Mul_2_output_0, /model.22/Sigmoid_output_0
Output(s): output0
Op type: Concat

So.. i find some instructitons when is describes that i should use configurations file ".yaml:

github.com/hailo-ai/hailo_model_zoo

hailo_model_zoo/cfg/networks/yolov8n.yaml

master

base:
- base/yolov8.yaml
postprocessing:
  device_pre_post_layers:
    nms: true
  hpp: true
network:
  network_name: yolov8n
paths:
  network_path:
  - models_files/ObjectDetection/Detection-COCO/yolo/yolov8n/2023-01-30/yolov8n.onnx
  alls_script: yolov8n.alls
  url: https://hailo-model-zoo.s3.eu-west-2.amazonaws.com/ObjectDetection/Detection-COCO/yolo/yolov8n/2023-01-30/yolov8n.zip
info:
  task: object detection
  input_shape: 640x640x3
  output_shape: 80x5x100
  operations: 8.74G
  parameters: 3.2M
  framework: pytorch

This file has been truncated. show original

github.com/hailo-ai/hailo_model_zoo

hailo_model_zoo/cfg/base/yolov8.yaml

master

base:
- base/yolo.yaml
postprocessing:
  meta_arch: nanodet_v8
  anchors:
    scale_factors:
    - 0.5
    - 0.5
    regression_length: 15
  device_pre_post_layers:
    sigmoid: true
  nms_max_output_per_class: 300
  post_nms_topk: 300
  nms_iou_thresh: 0.7
  score_threshold: 0.001

what is it???
anchors:
scale_factors:
- 0.5
- 0.5
regression_length: 15

github.com/hailo-ai/hailo_model_zoo

hailo_model_zoo/cfg/alls/generic/yolov8s.alls

master

normalization1 = normalization([0.0, 0.0, 0.0], [255.0, 255.0, 255.0])
change_output_activation(conv42, sigmoid)
change_output_activation(conv53, sigmoid)
change_output_activation(conv63, sigmoid)
nms_postprocess("../../postprocess_config/yolov8s_nms_config.json", meta_arch=yolov8, engine=cpu)

performance_param(optimize_for_power=True)

github.com/hailo-ai/hailo_model_zoo

hailo_model_zoo/cfg/postprocess_config/yolov8n_nms_config.json

master

{
    "nms_scores_th": 0.2,
    "nms_iou_th": 0.7,
    "image_dims": [
        640,
        640
    ],
    "max_proposals_per_class": 100,
    "classes": 80,
    "regression_length": 16,
    "background_removal": false,
    "bbox_decoders": [
        {
            "name": "yolov8n/bbox_decoder41",
            "stride": 8,
            "reg_layer": "yolov8n/conv41",
            "cls_layer": "yolov8n/conv42"
        },
        {
            "name": "yolov8n/bbox_decoder52",

This file has been truncated. show original

normalization1 = normalization([0.0, 0.0, 0.0], [255.0, 255.0, 255.0])
change_output_activation(conv42, sigmoid)
change_output_activation(conv53, sigmoid)
change_output_activation(conv63, sigmoid)
nms_postprocess(“../../postprocess_config/yolov8s_nms_config.json”, meta_arch=yolov8, engine=cpu)

Why is the normalization and output changing?
I saw on the graph after converting from onnx to har that my architecture is changing and I don’t know why.

Why do I have to use images from my dataset when using the zoo model?

github.com/hailo-ai/hailo_model_zoo

docs/DATA.rst

master

.. _Datasets:

Datasets
========

| The Hailo Model Zoo works with TFRecord files which store the images and labels of the dataset for evaluation and calibration.
| The instructions on how to create the TFRecord files are given below. By default, datasets are stored in the following path:

.. code-block::

   ~/.hailomz

It is recommended that the user defines the data directory path by setting the ``HMZ_DATA`` environment variable.

.. code-block::

   export HMZ_DATA=/new/path/for/storage/


* `Datasets`_

This file has been truncated. show original

Should I prepare the data in the same format as in the examples? Labels, images, folder tracking / val

And how to use config files?

github.com/hailo-ai/hailo_model_zoo

docs/YAML.rst

master


.. _yaml_description:

Ha    * | **normaliz  * | **padding_color** *(['integer', '  * | **bgr2rgb** *(boolean)*\ - ``evaluation`` and ``postprocessing`` properties aren't needed for compilation as they are used by the Model Zoo for model evaluation
  (which isn't supported yet for retrained models). Also the ``info`` field is just used for description.

  - Only in the YOLOv4 family, the ``evaluation.classes`` and ``postprocessing.anchors.sizes`` fields are used for compilation,
    that's these values should be updated even if just for compilation of the BGR to RGB layer.
    | In some training frameworks, the models are trained on BGR inputs. When we want to feed RGB images to the network (whether in the MZ or in the user application),
      we need to transform the images from RGB to BGR. The MZ automatically inserts this layer into the on-chip model.
    | We have already set the "bgr2rgb" flag in the yaml files that correspond to the relevant retraining dockers. Default: ``False``.'])*\ : In the training environments, the input images to the model have used this color to indicate "padding" around resized images. Default: ``114`` for YOLO architectures, ``0`` for others._in_net** *(boolean)*\ : Whether or not the network includes an on-chip normalization layer. If so, the normalization layer will appear in the .alls file that is used. Default: ``False``.
      | Example alls command: ``normalization1 = normalization([123.675, 116.28, 103.53], [58.395, 57.12, 57.375])``
      | If the alls doesn't include the required normalization, then the MZ (and the user application) will apply normalization before feeding inputs to the network Model Zoo YAML Description
================================

Properties
----------


* | **network**

This file has been truncated. show original

…there is too much information out there, making me a little lost and I don’t know how to convert onnx to hef correctly

p1221371923 · March 6, 2025, 3:30pm

Here is also

github.com/hailo-ai/hailo_model_zoo

hailo_model_zoo/cfg/base/yolo.yaml

master

base:
- base/coco.yaml
preprocessing:
  network_type: detection
  input_shape:
  - 640
  - 640
  - 3
  meta_arch: yolo_v5
  padding_color: 114
postprocessing:
  nms_iou_thresh: 0.45
  score_threshold: 0.01
  meta_arch: yolo_v5
  anchors:
    strides:
    - 8
    - 16
    - 32
    sizes:

This file has been truncated. show original

but hm, when i change input shape i shoudl change eanchors values?? but how?
